Size Images Module Name Brand Touch Panel Aspect Ratio Contrast Ratio Tech Type Resolution Active Area(mm) Luminance
(nits)
NTSC Viewing Angle Interface
4.3"


Download The Pdf
TSW080TN01-40NM01 TSW080TN01-40NM01 TEKSWO no 4:3 700 TFT 1024*3(RGB)*768 162.048*121.536 250 50% 50/70/70/70 40pin FPC, LVDS
8"


Download The Pdf
TSW080TI01-40NM01 TSW080TI01-40NM01 TEKSWO no 4:3 800 IPS 1024*3(RGB)*768 162.05*121.54 350 50% 85/85/85/85 40pin connector ,LVDS
9"


Download The Pdf
TSW090TN01-50NM04 TSW090TN01-50NM04 TEKSWO no 16:9 500 TFT 800*3(RGB)*480 198*111.696 120 50% 70/70/70/70 50pin FPC, Parallel 24bit RGB
9"


Download The Pdf
TSW090TN01-50NM03 TSW090TN01-50NM03 TEKSWO no 16:9 500 TFT 800*3(RGB)*480 198*111.696 250 50% 70/70/70/70 50pin FPC, Parallel 24bit RGB
9"


Download The Pdf
TSW090TN01-50NM02 TSW090TN01-50NM02 TEKSWO no 16:9 500 TFT 800*3(RGB)*480 198*111.696 180 50% 70/70/70/70 50pin FPC, Parallel 24bit RGB
10.1"


Download The Pdf
TSW101TI01-40NM02 TSW101TI01-40NM02 TEKSWO no 16:10 800 IPS 1280*3(RGB)*800 216.96*135.6 350 50% 85/85/85/85 40pin connector ,LVDS
