| Size | Images | Module Name | Brand | Touch Panel | Aspect Ratio | Contrast Ratio | Tech Type | Resolution | Active Area(mm) | Luminance (nits) |
NTSC | Viewing Angle | Interface | ||
7"
 |
|
TSW070TN01-40NM02 | TEKSWO | no | 16:9 | 700 | TFT | 1024*3(RGB)*600 | 153.6*90.0 | 250 | 50% | 70/75/75/75 | 40pin FPC, LVDS | ||
|
7"
|
|
TSW070TN01-40NM01 | TEKSWO | no | 16:9 | 800 | TFT | 1024*3(RGB)*600 | 153.6*90.0 | 250 | 50% | 70/75/75/75 | 40pin FPC, LVDS | ||
|
7"
|
|
TSW070TI01-40NM01 | TEKSWO | no | 16:10 | 800 | IPS | 1280*3(RGB)*800 | 149.76*93.6 | 350 | 50% | 89/89/89/89 | 40pin connector ,LVDS | ||
|
7"
|
|
TSW070TF01-40NM01 | TEKSWO | no | 16:9 | 500 | TFT | 1024*3(RGB)*600 | 153.6* 90.0 | 350 | 50% | 85/85/85/85 | 40pin FPC, LVDS | ||
|
8"
|
|
TSW080TN01-40NM04 | TEKSWO | no | 4:3 | 700 | TFT | 1024*3(RGB)*768 | 162.048*121.536 | 220 | 50% | 50/70/70/70 | 40pin FPC, LVDS | ||
|
8"
|
|
TSW080TN01-40NM03 | TEKSWO | no | 4:3 | 700 | TFT | 1024*3(RGB)*768 | 162.048*121.536 | 320 | 50% | 50/70/70/70 | 40pin FPC, LVDS | ||
|
8"
|
|
TSW080TN01-40NM02 | TEKSWO | no | 4:3 | 700 | TFT | 1024*3(RGB)*768 | 162.048*121.536 | 250 | 50% | 50/70/70/70 | 40pin FPC, LVDS | ||
|
4.3"
|
|
TSW080TN01-40NM01 | TEKSWO | no | 4:3 | 700 | TFT | 1024*3(RGB)*768 | 162.048*121.536 | 250 | 50% | 50/70/70/70 | 40pin FPC, LVDS | ||
|
8"
|
|
TSW080TI01-40NM01 | TEKSWO | no | 4:3 | 800 | IPS | 1024*3(RGB)*768 | 162.05*121.54 | 350 | 50% | 85/85/85/85 | 40pin connector ,LVDS | ||
|
10.1"
|
|
TSW101TI01-40NM02 | TEKSWO | no | 16:10 | 800 | IPS | 1280*3(RGB)*800 | 216.96*135.6 | 350 | 50% | 85/85/85/85 | 40pin connector ,LVDS | ||
