Total 6 Records |
|||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Size | Images | Module Name | Brand | Touch Panel | Aspect Ratio | Contrast Ratio | Tech Type | Resolution | Active Area(mm) | Luminance (nits) |
NTSC | Viewing Angle | Interface | ||
10.4"
 |
|
G104V1-T03 | CHIMEI-INNOLUX | Optional | 4:3 | 1500:1 | TFT | 640*3(RGB)*480 | 211.2x158.4 | 500 | -- | 88/88/88/88 | CMOS/TTL | ||
|
10.4"
|
|
G104AGE-L02 | CHIMEI-INNOLUX | Optional | 4:3 | 700:1 | TFT | 800*3(RGB)*600 | 211.2 x 158.4 | 400 | -- | 70/70/80/80 | LVDS (1 ch, 6/8-bit) | ||
|
10.4"
|
|
G104S1-L01 | CHIMEI-INNOLUX | Optional | 4:3 | 700 | TFT | 800*3(RGB)*600 | 211.2×158.4 | 400 | -- | 70/70/80/80 | LVDS (1 ch, 6/8-bit) | ||
|
10.4"
|
|
LSA40AT9001 | CHIMEI-INNOLUX | Optional | 4:3 | 500 | TFT | 800*3(RGB)*600 | 211.2 x 158.4 | 250 | 50% | 50/60/70/70 | 60pin FPC(1*60pin), Parallel 18bit RGB | ||
|
10.4"
|
|
G104X1-L03 | CHIMEI-INNOLUX | Optional | 4:3 | 1000:1 | TFT | 1024*3(RGB)*768 | 210.432*157.824 | 350 | -- | 88/88/88/88 | LVDS | ||
|
10.4"
|
|
G104X1-L04 | CHIMEI-INNOLUX | Optional | 4:3 | 1000:1 | TFT | 1024*3(RGB)*768 | 210.432*157.824 | 500 | 57% | 88/88/88/88 | LVDS | ||
Total 6 Records |
|||||||||||||||
