15.0" TFT LCD Display

G150XGE-L04

  • Download
  • back
MOQ: ≥ 10pcs
Lead Time: 3 working days FCA Hongkong after receiving payment
Payment: T/T, Paypal, West Union
Warranty: 1 year

Product Name:
G150XGE-L04
Touch Panel:
No
Screen Size:
15.0"
Aspect Ratio:
4:3
Display Mode:
Transmissive
Resolution:
1024×768
PPI ( Pixel per inch ):
85
Module/Panel Size(mm):
326.5×253.5×12
Active Area(mm):
304.1×228.1
Dot Pitch(mm):
0.297(W) X0.297(H)
Surface Treatment:
Antiglare(Haze25%), Hard coating (3H)
Viewing Angle (Tpy.)θT/θB/θL/θR:
70/70/80/80
Viewing direction:
6 O'Clock
NTSC:
--
Luminance(nits):
400
Contrast Ratio:
700:1
Response Time(ms):
8/17 (Typ.)(Tr/Td)
Consumption (W) Total:
10.6
Panel Weight (g):
835.0
Interface:
LVDS (1 ch, 6/8-bit)
Operation Temperature( ℃):
-30~80
Storage Temperature (℃):
-40~85
Lamp type:
White LED backlight display

Wholesale InnoLux G150XGE-L04 display TFT-LCD from China

       Searching InnoLux G150XGE-L04 display tft-lcd at a reasonable price? This page includes a rich selection of InnoLux G150XGE-L04 display tft-lcd! We’ve also got InnoLux G150XGE-L04 display panel. You can shop wholesale InnoLux G150XGE-L04 display tft-lcd panel from Chinese InnoLux G150XGE-L04 display tft-lcd wholesalers with high quality and low prices. Our online wholesalers often offer special discounts and sales like InnoLux G150XGE-L04 display tft-lcd. If you want quotation or more details, please send Email to:
